Subsea cables deliver power to offshore Safaniya upgrade project

Saudi Aramco has connected a 230-kV, 46-km (28.6-mi) submarine composite cable to the TP-20 tie-in platform offshore Saudi Arabia.

Jun 30th, 2015
TP-20 tie-in platform offshore Saudi Arabia
TP-20 tie-in platform offshore Saudi Arabia

Offshore staff

DHAHRAN, Saudi ArabiaSaudi Aramco has connected a 230-kV, 46-km (28.6-mi) submarine composite cable to the TP-20 tie-in platform offshore Saudi Arabia.

This is part of a first-phase program to upgrade the field’s facilities under the“Safaniya Master Plan.”

TP-20 will be the main crude oil gathering and power supply hub for the North Safaniya offshore field. It will supply 152 MW of electric power via the power/fiber cable linked to a newly-built 380/230 kV onshore substation built by Saudi Electricity Co.

Aramco claims the submarine composite cable is the longest of its kind in the world and was installed as a single piece without a field splice.

The entire length of the cable was transported from the manufacturer on one deepwater cable laying vessel. With the help of a shallow-water cable laying barge, the cable was installed from onshore to TP-20.

TP-20 with its substation weighs more than 6,000 metric tons (6,613 tons) necessitated installation via a float-over.

Subsequently, TP-18 and nine wellhead platforms in the central Safaniya field were also successfully powered up.

TP-18 is designed to provide 62 MW via a 44-km (27-mi), 3-core 115-kV submarine composite cable from a newly-built 230/115 kV onshore substation.

06/30/2015
